[KONICA MINOLTA CM-25cG] 휴대용 컬러 및 광택 측정기 / 분광계측기 / Portable Color and Gloss Meter
KONICA MINOLTA CM-25cG Portable Color and Gloss Meter

주요특징 (Features)

• 광택과 색을 동시에 평가할 수 있는 자동차 내장 측정용 Two-in-one 분광측색계
• 자동차 내장 평가에 특화된 장비
• 세계 최초”로 45°c:0°의 조명 수광 광학계와 실제 고성능 60° 광택 센서를 탑재
• 질감이나 표면 구조에 대한 높은 정확성과 반복성
• 한 번의 측정만으로 1초 안에 색과 광택을 동시에 측정
• 45°:0° 조명 수광 광학계 중 광학 샘플 뷰어를 장착한 최초의 계측기

주요용도

• 자동차 내장 부품의 색과 광택 측정

상세설명 (Description)

The CM-25cG is a compact and lightweight portable spectrophotometer with 45°c:0° geometry and a true high performance 60°-gloss-sensor. The 45°c:0° geometry used is renowned for providing color values offering excellent correlation to visual perception. This is achieved by fully excluding surface effects of gloss and/or texture. The built-in gloss-sensor accurately measures surface gloss.

Being fully compatible to the previous CM-2500c model, the CM-25cG’s perfect circular optical system (defined as 45°c:0°) achieves high accuracy and repeatability, especially on textured or structured surfaces, regardless of measurement direction. Not only does it measure color, but also true 60°-gloss at the same time and, as a world premiere, not only for standard MAV aperture size (10mm) but also for small measurement areas with 3mm spot size.

The CM-25cG is lightweight and uses a large and easy-to-read color display to show and manage measurement data either numerically or graphically. For correct positioning on a sample, the CM-25cG is the first device offering a true optical sample viewer in a 45°:0° geometry instrument.

Technical specifications
