[VICTOR 825A] 코팅 두께 측정기 / Coating Thickness Gauges
VICTOR 852A Coating Thickness Gauges
주요특징 (Features)
• Clamp AC current measurement: 40A, 100A, 400A, 1000A, 4 measurement range, the true RMS RMS AC current measurement, the basic accuracy: 2%.
• AC voltage measurement: 15V, 100V, 300V, 600V, 4 measurement range, the exchange of RMS voltage measurement, the basic accuracy: 1.2%.
• AC voltage frequency measurement: 20 ~ 500Hz, the basic accuracy: 0.5%.
• Can be single-phase, three-phase three-wire, three-phase four-wire balanced system measurement.
• Active power, reactive power, apparent power measurement, in accordance with the voltage and current measurement range combination determined.
• Power factor, phase angle ф measurement, the phase difference between the voltage and current signals can be measured, the equivalent basic accuracy: ± 1o.
• Active energy, reactive energy, apparent energy measurement, the basic accuracy: 3%.
Phase sequence detection, detection phase sequence 3 phase system: positive sequence, reverse sequence, phase loss.
• MAX / MIN measurement, voltage, current, active power, apparent power measurement.
• All measurement functions are automatic range.
• Measurement data display remains (DIS_HOLD).
• Large-screen multi-data display, voltage values can be displayed at the same time, the current value, power and other related measurement information.
• Two kinds of data recording functions: manual recording and timed recording, and can easily query the recording data, internal memory can be stored separately Manually record 1000 sets of measurement data, timed recording 1000 sets of measurement data.
• Multiple LCD display with white LED backlight.
• The meter communicates with the computer via infrared serial interface USB-IR
Technical specifications
* For one year after calibration, 23 ℃ ± 5 ℃, 0 ~ 70% RH, accuracy = ± (% of reading + LSD)
* AC current measurement parameters | |||
MAX allows current | 1000Arms continuous | ||
---|---|---|---|
Conductor position | Located within 0.7% of the jaw center | ||
External magnetic field | 400A / m MAX sensor is 2A | ||
MAX allowable loop voltage | 600Vrms (insulated conductor) | ||
Current (True RMS) I | |||
Range (exact range) | Resolution | Accuracy | |
45Hz to 66Hz | 20Hz to 45Hz, 66Hz to 500Hz | ||
40A | 0.1A | 1.5% + 5 | 2% + 5 |
100A | 0.1A | 1.5% + 5 | 2% + 5 |
400A | 0.1A | 1.5% + 5 | 2% + 5 |
1000A | 1A | 1.5% + 5 | 2% + 5 |
* AC voltage measurement parameters | |||
Voltage (True RMS) U | |||
Range (exact range) | Resolution | Accuracy | |
---|---|---|---|
45Hz to 66Hz | 20Hz to 45Hz, 66Hz to 500Hz | ||
15V | 0.1V | 1.2% + 5 | 1.5% + 5 |
100V | 0.1V | 1.2% + 5 | 1.5% + 5 |
300V | 0.1V | 1.2% + 5 | 1.5% + 5 |
600V | 0.1V | 1.2% + 5 | 1.5% + 5 |
* Single-phase power meter way to measure single-phase power parameters | ||||||||||||||||||||||||||||||||
Measurement conditions | Single phase, 50 / 60Hz | |||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Measuring range | Effective current measurement range 5A to 1000A Effective voltage measurement range 20V to 600V | |||||||||||||||||||||||||||||||
Over range | Regardless of current (line current) or voltage (line voltage) over range, the power measurement is over range | |||||||||||||||||||||||||||||||
Active Power Measurement (W) Reactive power measurement (VAr) Apparent Power Measurement (VA) |
|
|||||||||||||||||||||||||||||||
measurement accuracy | 15V / 1000A Range: 3% + 10; the remaining range: 3% +5 | |||||||||||||||||||||||||||||||
Resolution | <100K: 0.01; ≥100K: 0.1 |
* 1ΦPF and 3ΦPF phase angle and power factor | |||||||||
Measurement conditions | Single-phase / balanced three-phase, 50 / 60Hz, sine wave | ||||||||
---|---|---|---|---|---|---|---|---|---|
Measuring range | Effective current measurement range 10A to 1000A Effective voltage measurement range 45V to 600V | ||||||||
Phase angle measurement Φ |
|
||||||||
Power factor measurement |
|
* Balance three-phase power measurement parameters | ||||||||||||||||||||||||||||||||
Measurement conditions | Balance three-phase, 50 / 60Hz, sine wave | |||||||||||||||||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Measuring range | Effective current measurement range 5A to 1000A Effective voltage measurement range 20V to 600V | |||||||||||||||||||||||||||||||
Over range | Regardless of current (line current) or voltage (line voltage) over range, the power measurement is over range | |||||||||||||||||||||||||||||||
Active Power Measurement (W) Reactive power measurement (VAr) Apparent Power Measurement (VA) |
|
|||||||||||||||||||||||||||||||
measurement accuracy | 3% + 10 (COSΦ = 1) | |||||||||||||||||||||||||||||||
Resolution | <100K: 0.01; ≥1000K: 1; <1000K ~ ≥100K: 0.1 |
* Frequency measurement parameters | |||||||
Measurement conditions | Effective voltage measurement range 10V to 600V | ||||||
---|---|---|---|---|---|---|---|
Measuring range measurement accuracy |
|
* Energy parameters | |||||||
Measurement conditions | Single phase, 50 / 60Hz | ||||||
---|---|---|---|---|---|---|---|
Measuring range | Effective current measurement range 5A to 1000A Effective voltage measurement range 20V to 600V | ||||||
Active Energy Measurement (KWh) |
|
* Other parameters | |
Jaw opening | 50mm |
---|---|
Jaw capacity | round: Ф 55 mm |
Response time | 0% ~ 90% of range, MAX3.5 seconds; phase measurement MAX4 seconds |
Common mode rejection | 50Hz / 60Hz (Rs = 1kΩ) ≥ 80dB |
Zero suppression | 5 bits (voltage and current measurement) |
MAX surge current | 2.5 times MAX (1.7 times for 1000A and 600V) |
Measurement refresh time | 500ms / time |
